Solis-S5-GC40K-DC (4 MPPT)

1100V three-phase inverter
Maximum input current: 32A
Certified 0 injection
Overvoltage, short circuit, output overcurrent and DC reverse polarity protection
Standard 5-year warranty extendable up to 20 years

S5-GR3P10K
S5 10kW 3Ph Inverter, 2 MPPT, DC SW
Brand: Solis
Manufacturer code: 021903230020
Inverter power: 10kWn

Solis-1P-Meter-CT*1

Single-phase indirect measurement wattmeter
Included open-core toroidals with per-phase measurement capacity of up to 150A and 5 meters of cable
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
DIN35 rail mounting

2 MPPT Hybrid Single Phase Inverter
Maximum input voltage: 600V
Maximum input current: 15 A / 15 A
Maximum efficiency: 96.5%
DC reverse polarity protection/output overcurrent/short circuit and overvoltage
Protection level: IP65
5-year warranty extendable up to 20 years
Inverter power: 3kWn

Solis S5-GR1P1.5K-M (1.5 kW)

Maximum input voltage: 600 V
Maximum input current: 12.5 A
Number of MPPTs/Number of inputs: 1/1
97.3% maximum efficiency
Integrated AFCI (DC Arc Fault Circuit Protection)
5 year warranty extendable to 20 years
Inverter power: 1.5kWn

2 MPPT Hybrid Single Phase Inverter
Maximum input voltage: 600V
Maximum input current: 15 A / 15 A
Maximum efficiency: 96.5%
DC reverse polarity protection/output overcurrent/short circuit and overvoltage
Protection level: IP65
10-year warranty extendable up to 20 years
Inverter power: 3.6kWn

Solis-3P-Meter (Direct)

Three-phase direct measurement wattmeter
DIN35 rail mounting
Controls consumption and discharges 0 into the network, and also measures the energy exported to compensate for surpluses.
LCD screen for real-time viewing of measurements
Communication with the inverter via RS485

Features:

Indirect measurement wattmeter, installation without the need to modify the customer's installation
DIN35 rail mounting
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
Ability to use other toroidals with secondary at 5 amps simply by setting the transformation ratio

Solis-1P-Meter

Single-phase direct measurement wattmeter
Communication with the inverter via RS485
DIN rail 35
8-bit LCD display
Measuring range (A) : 10(60A)

S6-GC3P50K-NV-ND
S6 50kW 3Ph Inverter, 4 MPPT, DC SW, PID
Brand: Solis
Manufacturer code: 025102010021
Inverter power: 50kWn

The SI-RS485TC-T is used to record the intensity of solar irradiance.
In addition, it can also record the temperature of the measuring cell module.

Supply voltage:
24 V DC (12...28 V DC)
Current consumption:
typical 35 mA
Galvanic isolation:
1000 V between power supply and RS485 bus
Current measurement shunt:
0.1Ω (TK = 30ppm/K)
Measuring range:
0… 1400 W/m²
cable length: 3m

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

Modbus irradiance sensors are designed for professional use in industrial, commercial and photovoltaic plants.

The irradiance sensor works as a concentrator for several sensors. All measured weather data is transmitted to the data loggers and receiving units via a 2-wire RS485 bus with Modbus RTU protocol.

- Class A compliance.
- Quick and easy installation.
- Similar structure with photovoltaic panels.
- Free software update.
- Compatible with SunSpec (for Modbus RTU).
- Remote configuration service.
- 5 years warranty.

SPF 2/1-40/1000/15 (122) - Photovoltaic protection panel
for 2 inputs + 1 outputs.
1000Vdc, 15A per input, with fuse, fuse base and
1000vdc 30A disconnector. Surge protection
1000vdc 40A. Enclosure of 12 modules in ABS. Connectors
stuffing box.

SPF 3/1-40/1000/15 (122) - Photovoltaic protection panel
for 3 inputs + 1 outputs. 1000Vdc, 15A per input, with
fuse, fuse base and disconnector. 12 envelope
ABS modules with cable glands.

2P single-phase differential switch. In=30mA (40A) Class B (smooth pulsating alternating leakage currents up to 1kHz). With automatic reset.

2P single-phase differential switch. In=100mA (40A) Class A (alternating leakage currents or p). With automatic reset.

2P single-phase differential switch. In=30mA (40A) Class B (smooth pulsating alternating leakage currents up to 1kHz).

It is a two-axis static ultrasonic anemometer used to make accurate measurements of wind speed and direction under all environmental conditions. It is capable of measuring wind speeds of up to 85 m/s without losing precision.

It has a heating option for quick defrosting. A model with an anodized aluminum alloy casing with anti-corrosion coating is available. This feature allows the instrument to be used even in particularly aggressive environments. The anemometer meets the requirements of MIL-STD-810G Method 509.6 (salt spray corrosion test). Its high immunity to electromagnetic interference makes it suitable for measurements in electrically noisy environments.

All measured weather data is transferred to the data loggers and receiving units via a 2-wire RS485 bus with Modbus RTU protocol. This sensor is also equipped with two analog outputs for wind speed and direction, factory configurable within 4-20 mA (standard), 0…1 V, 0…5 V or 0…10 V (to be specified when ordering).

ATMOCE DTSU Chint Meter.
