COMPLEMENTOS

Solis-1P-Meter-CT*1

Single-phase indirect measurement wattmeter
Included open-core toroidals with per-phase measurement capacity of up to 150A and 5 meters of cable
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
DIN35 rail mounting

Solis RHI-3K-48ES-5G-DC 3 kW single-phase hybrid inverter for low-voltage batteries, with backup output and 2 MPPTs. Includes a single-phase meter. Dimensions: 333×505×249 mm. Weight: 18.3 kg. IP65 protection and 5-year warranty.

Solis S5-GR1P1.5K-M 1.5 kW single-phase grid-tied inverter with 1 MPPT and 1 input. Maximum voltage 600 V, MPPT range 50–500 V, IP65 protection and 5-year warranty.

Solis S5-EH1P3.6K-L Smart 3.6 kW single-phase hybrid inverter for low-voltage batteries, with backup output and 2 MPPTs. Includes a single-phase meter. Dimensions: 333×505×249 mm. Weight: 18.3 kg. IP65 protection and 10-year warranty.

Solis-3P-Meter (Direct)

Three-phase direct measurement wattmeter
DIN35 rail mounting
Controls consumption and discharges 0 into the network, and also measures the energy exported to compensate for surpluses.
LCD screen for real-time viewing of measurements
Communication with the inverter via RS485

Features:

Indirect measurement wattmeter, installation without the need to modify the customer's installation
DIN35 rail mounting
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
Ability to use other toroidals with secondary at 5 amps simply by setting the transformation ratio

Solis-1P-Meter

Single-phase direct measurement wattmeter
Communication with the inverter via RS485
DIN rail 35
8-bit LCD display
Measuring range (A) : 10(60A)

Solis S6-GC3P50K04-NV-ND 50 kW three-phase grid-tied inverter with 4 MPPTs / 8 PV inputs, 180 to 1,000 V MPPT range, maximum current of 42 A per MPPT and IP66 protection. Dimensions: 508×612×288 mm. Weight: 35.8 kg. Warranty: 5 years. C5 version. Solis code: 025102010021.

Includes cable (ca. 130 cm) and MC4 connector system (IP 68)
Anodized aluminum frame
High quality solar cells
Version with 10 busbars
30 units per pallet

Batería de alto voltaje
10 años de garantía

Ambient Temperature Sensor, PT1000,
Measuring range: -40...+85°C,
Housing: Stainless steel tube, IP68,
Incl. 1.5 m PUR cable,
Incl. UV resistant solar radiation shield.

Wind speed sensor with digital output,
Digital Output: Reed relay up to 100 Hz,
Measuring Range: 0.9...60 m/s,
Incl. 3m cable with connector

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

SUNMETER PRO WIND with LAMINATED solar cell with
SOLAR GLASS and with the same elements as in PV
module. Class A; Modbus RS485 output, Irradiance
Previous ± 2.1%, Previous Temp. ± 0.5°C, wind speed. Houses in
anodized aluminum. With mounting bracket and
Temperature probe input. Accuracy 2.%. service
recalibration after 12/18 months included.

For communication with a pulse anemometer it is necessary:
- 2 x M12 Male 8 pin
- 1 x M12 Y connector for Soluzione anemometer
- 1 x M12 Female 8 pin output to datalogger

Trina 575Wp TSM-DE19R VERTEX

Temperature sensor by modulului will increase the temperature of the solar panourilor spate in Celsius (°C) folosind or PT1000 probe. Probe, folosită pentru măsurarea temperaturii părții din spate a modulului, este plasată între două foi din spate cu lie EVA. This temperature sensor module is compatible with the bottom of the SEVEN temperature sensor.

Main advantage of the sensor is this structure, which is similar to the part in the spate of the photovoltaic module. Mainly, the transfer behavior of heat to the sensor and the photovoltaic module is similar, this is the case.

Part number 3S-MT-PT1000
Senzor tip PT1000
Temperature range -40°C to +85°C
Accuracy ±0.1°C
Rezoluție 0.1°C
Ieșire PT1000
Electrical connection LIYYC11Y PUR Cable of 3 m, resistant to UV rays and intemperii
Operating temperature -40°C to +85°C
Sensor capacity size Ø 35mm x 3mm
Greutate 77 gr
Evaluate IP IP 67
Material capac senzor Foaie din spate laminată (EVA – Tedlar)
Mounting method Autocolant 3m pe spatele panoului
Standardul Class A conform to IEC 60751:2022

Temperature Sensor Module, PT1000 with output
analog,
Measuring range: -40°C to +85°C
Power supply 12...30 V DC
4-20mA output
Accuracy: ±0.1°C
Housing: Plastic housing with aluminum plate, H x
W x L: 12mm x 50mm x 50mm
3 m PUR cable, UV and weather resistant
The Class A Standard according to IEC 60751:2022

The albedometer is used to measure the irradiance values and albedo ratio of bifacial panels. In addition to the aforementioned measurements, it also includes the internal temperature sensor of the cell. Supplied together with mounting bracket and cable.

All measured meteorological data are transferred to dataloggers and
receivers through a 2-wire RS485 bus with Modbus RTU protocol.

The PV albedometer provides the data necessary to calculate the coefficient of performance and measure solar albedo when using bifacial panels.

2 pcs. Silicon cell sensors with internal temperature
sensor,
Irradiance: 0...1600 W/m2(Temp. Compensated),
Output: RS485 port (includes 3 m PUR cable)
Communication protocol: MODBUS RTU and
SunSpec compatible

Solar-log compatible

SPF 2/1-40/1000/15 (122) - Photovoltaic protection panel
for 2 inputs + 1 outputs.
1000Vdc, 15A per input, with fuse, fuse base and
1000vdc 30A disconnector. Surge protection
1000vdc 40A. Enclosure of 12 modules in ABS. Connectors
stuffing box.
