Compatible with Victron and Huawei L1

Photovoltaic protection panel for 2 inputs + 2 outputs. 1000Vdc, 15A per input, with fuse and fuse base. Enclosure of 12 modules in ABS. MC4 connectors.

Openable toroidal IAP 1000/5

Openable transformers measuring 1500/5

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

A power meter transmits the power measurement quantity to the SolarLog for analysis. It serves as a consumption meter, showing a comparison of the power produced and consumed. It can be configured to operate with the SolarLog in three different modes:
- Measurement of energy consumption for optimal use of the generated power.
- Measure the total amount of energy that has been poured into the grid.
- Measurement of energy production of inverters that are not managed directly by SolarLog.

AC current meter

Bidirectional three-phase meter.
Rated voltage 230 V/400 V
Frequency 50 Hz/±5%
Rated current/limit per phase conductor 5 A/63 A (>63 A combined with external current transformers)
Starting current <25mA
Connection section 10 mm² to 16 mm² 1) (for 63 A protection)

With external voltage supply 12 to 28 VDC, 3 m cable, integrated microprocessor, active temperature compensation, integrated temperature measurement on RS485 interface, with sockets for an external temperature sensor (Pt1000) and an external wind speed sensor (connectors not included), protocol: MODBUS

Victron 275A disconnector

Compact equipment for decentralized systems and large-scale photovoltaic systems due to its high power density. Output voltage 690V

“Active cooling” with speed-controlled fans ensure optimal
optimal cooling with lower energy consumption, maximizes production
due to temperature reduction

Max power of PV generator: 360 kWp
Max input voltage 1500V
Max input current/Max short circuit current: 180 A/325 A
Number of MPP followers: 1
Certificate for Spain and Portugal
5 year warranty

Stops power losses
Prevents the PID effect
Measures insulation resistance.
IP56
MC4 connection
Output for 1 MPPT, chains up to 1000V with common negative
1 relay output

35A MPPT charge regulator for 12, 24, 36 and 48 volt battery systems and up to 150V photovoltaic field, from the Victron Energy brand, SmartSolar MPPT 150/35 model.

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / U AC1.0 / 1.0 kV DC 1.5 / 1.5 kV
Weather and UV resistance

The BENNING PV 2 is a professional measurement device designed for the safe, precise and efficient verification of photovoltaic installations, both in direct current (DC) and alternating current (AC). Ideal for installers, maintenance technicians and EPC companies, this device allows essential testing according to IEC 62446.

What is it for?
This instrument is essential for:

Verify the performance and safety of photovoltaic strings and inverters.

Measure voltage and current in open circuit (Voc, Isc).

Detect insulation faults between conductors and ground (insulation test up to 1000 V DC).

Check the polarity, continuity and general condition of the panels.

Carry out post-installation technical audits or preventive maintenance.

Typical applications
Residential, commercial and industrial solar installations.

Verification of strings before connection to the inverter.

Certification of new systems in accordance with regulations.

Diagnosis of poor performance or failures in the field.

Key advantages:
Fast and accurate measurement at the touch of a button.

Compatible with modules up to 1000 V DC.

Data storage and download function to PC for reports.

Includes a test box and secure connection cables.

Portable, robust design and ready for outdoor use.

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / U AC1.0 / 1.0 kV DC 1.5 / 1.5 kV
Weather and UV resistance

Rated power: 110000W
12 independent MPP supporters.
Without display.
IP65.
Max power Photovoltaic generator:165000 Wp STC
Max input voltage 1100 V
MPP tracker voltage range/rated input voltage: 500 V to 800 V/ 585 V
Min/Start Input Voltage200V/250V
Max current input/per MPP follower: 26 A/40 A
Number of independent MPP follower entries/Strings per MPP follower entry: 12/2

Indirect measurement.

85A MPPT solar charge regulator for 12, 24, 36 or 48 volt battery systems and up to 250V photovoltaic field, from the Victron Energy brand, model SmartSolar MPPT 250/85-Tr VE.Can (with connection for solar input with screw)

Control center and energy manager via Ethernet, includes Energy Meter.
