COMPLEMENTOS

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

With external 12 to 28 VDC power supply, 3 m connection cable, integrated microprocessor, active temperature compensation, integrated measurement of calibrated solar cell temperature and an RS485 interface, protocol: MODBUS, with permanently connected external ambient temperature sensor (Pt1000, cable length 3 m)

Ambient temperature sensor to connect to Si-RS485TC-2T-v, Pt1000 class A, incl. 3 m cable and plug-in connector (IP67)

MC shunt bushing MC4 (negative pole). For simple parallel or series-parallel connection of photovoltaic modules.

MPPT 60A charge regulator for 12, 24, 36 or 48 volt battery systems and up to 250V photovoltaic field, from the Victron Energy brand, SmartSolar MPPT 250/60-Tr model.

The Victron EM24 Ethernet is a standard device for measuring the power and energy of a three-phase application, for example at the distribution box or for measuring the output of a PV inverter, AC generator or inverter or inverter/charger.

MC shunt bushing MC4 (negative pole). For simple parallel or series-parallel connection of photovoltaic modules.

MC4 4-6MM² FEEDBACK CONNECTOR
MC4 surface mount connectors form the interface between an inverter or distributor housing and a string.

MC4 bulkhead connector 4-6mm²
MC4 surface mount connectors form the interface between an inverter housing or PV panel.

ET330DINAV53HS1X

ELECTRICITY METER SE-WND-3Y-400-MB-K DIN-RAIL

POWER OPTIMIZER P505-P5 (MC4)

POWER OPTIMIZER S440 (2.3m/0.1m/0.1m)

JA_Solar 385Wp JAM60S20 MR HC Black Frame

Hanergy 370Wp Panel 1840*1040mm

SolarEdge 5kWn three-phase inverter

SUNMETER PRO with solar cell LAMINATED with SOLAR GLASS
and with the same elements as in the photovoltaic module.
Class A; Modbus RS485 output, Prec irradiance ± 2.1%, Prec temp. ±0.5°C.
Case in anodized aluminum. With mounting bracket and temperature
probe input Accuracy 2,%.
Recalibration service after 18/12 months included.

SmartSolar MPPT 250/60-MC4 Regulator

Single-phase meter for single-phase hybrid inverter with external CT –
SDM120CT (with 1 × TC)

S6-GR1P6K
S6 6.0kW 1Ph, 2 MPPT, DC SW, Meter Version
Brand: Solis
Manufacturer code: 021801110070
Inverter power: 6kWn
