Electric vehicle charging protection table according to ITC-BT-52.
4 Poles. 32A, POP 50:550 permanent and transient overvoltage protection.

Electric vehicle charging protection panel according to ITC-BT-52.
4 Poles. 40A, POP 50:550 permanent and transient overvoltage protection.

Sigenergy 12.5 kW bidirectional DC fast-charging module with an integrated 7.5 m CCS2 cable. Compatible with electric vehicles from 150 to 1,000 V, with IP66 protection, intelligent cooling and remote control through the mySigen App. Requires a Sigen Energy Controller.

EBick plinth with wheels that allows modules to be stacked up to 3 heights.
Recommended for small spaces where use is not possible
of pallet truck.

1000Vdc, 15A per input, with
fuse and fuse base + surges 40kA 1000vdc.
Enclosure of 3x18 modules. Box without drilling and with
stuffing box inside.

Differential Switch. RCCB 2P 40A 30mA type A (VE Charger suggestion)

[MD00138] BV2M-40/240 - Single-phase surge protectors Type 2
• Maximum service voltage Uc = 275 V. Protection level [N-T] Up = 1.2 kV. Maximum discharge current (8/20) Imax = 40 kA. Mounting on DIN rail, pluggable, width 1 module (18mm).

Measurements (H×W×D): 90×18×68 mm
Weight: 0.13kg
Technical source: MD Technological Equipment - BV2M-40/240 technical sheet

Temperature Sensor Module, PT1000 with output
analog,
Measuring range: -40°C to +85°C
Power supply 12...30 V DC
4-20mA output
Accuracy: ±0.1°C
Housing: Plastic housing with aluminum plate, H x
W x L: 12mm x 50mm x 50mm
3 m PUR cable, UV and weather resistant
The Class A Standard according to IEC 60751:2022

Photovoltaic protection panel with 7 inputs and 7 outputs of 1000vdc with 16A disconnector, 20A fuses in 10x38 and type II surge protection 40kA, 1000vdc. per string, double-insulated polyester hybrid envelope and transparent polycarbonate cover with 720x540x201 gasket, with cable gland, assembled and pre-wired.

Protection box
photovoltaic with 16 inputs and 16 outputs, mounted on a plate
800x600x300mm IP66 polyester cabinet with door
opaque Composed of 32 fuse bases and fuses
10x38 15A 1kV + surge protection BF3-
40/1000vdc with bulkhead, assembled and pre-wired.

Custom photovoltaic protection panel with 9 inputs of which 3 are double and 6 outputs with disconnector, fuse bases and 10x38 1000vdc 16A fuses in IDE IP65 3x18 enclosure in ABS, with wall grommets and cable gland for ground, assembled and pre-wired.

Combiner type photovoltaic protection panel

Custom-made with 13 inputs and 1 output with 1500 VDC 400A disconnector, + fuse bases and 14x85 1500vdc 16A fuses in IP66 polyester cabinet 747x536x300mm with opaque door, with wall grommet and cable gland for ground, assembled and pre-wired.

The albedometer is used to measure the irradiance values and albedo ratio of bifacial panels. In addition to the aforementioned measurements, it also includes the internal temperature sensor of the cell. Supplied together with mounting bracket and cable.

All measured meteorological data are transferred to dataloggers and
receivers through a 2-wire RS485 bus with Modbus RTU protocol.

The PV albedometer provides the data necessary to calculate the coefficient of performance and measure solar albedo when using bifacial panels.

2 pcs. Silicon cell sensors with internal temperature
sensor,
Irradiance: 0...1600 W/m2(Temp. Compensated),
Output: RS485 port (includes 3 m PUR cable)
Communication protocol: MODBUS RTU and
SunSpec compatible

NUMAX 12V 260 AH C100 225AH C20

This all-new communications center puts you in control of your system anytime, anywhere, and maximizes performance. Simply connect through our Victron Remote Management (VRM) portal, or access directly via the standalone GX Touch multi-function display or our VictronConnect app thanks to built-in Bluetooth functionality. This latest addition to the GX range combines all the best of connectivity, redefining smart energy solutions in every aspect.

K2-Light Guide 0.50 m SolidRail

FR Rod M10*250

15º aluminum triangle VXL15 (guide support leg 1600/465/1656mm)

Electric vehicle charging protection panel according to ITC-BT-52.
2 Poles, 32A, POP 50:550 permanent and transient overvoltage protection.
Resettable automatic

FR 01V8 Kit (8 modules)
