Your solar energy shop

Solis 36kw 5G Three Phase QUAD MPPT DC

4MPPT three-phase grid inverter (maximum 8 input strings)
Maximum input voltage: 1100V
MPPT voltage range: 200-1000V
Maximum input current: 26A
DC reverse polarity/short circuit/output overcurrent and temperature protection

Inverter power: 36kWn

Solis S5-EH1P3.6K-L Smart 3.6 kW single-phase hybrid inverter for low-voltage batteries, with backup output and 2 MPPTs. Includes a single-phase meter. Dimensions: 333×505×249 mm. Weight: 18.3 kg. IP65 protection and 10-year warranty.

Solis RHI-3.6K-48ES-5G-DC 3.6 kW single-phase hybrid inverter for low-voltage batteries, with backup output and 2 MPPTs. Dimensions: 333×505×249 mm. Weight: 18.3 kg. IP65 protection and 5-year warranty.

Solis-3P-Meter (Direct)

Three-phase direct measurement wattmeter
DIN35 rail mounting
Controls consumption and discharges 0 into the network, and also measures the energy exported to compensate for surpluses.
LCD screen for real-time viewing of measurements
Communication with the inverter via RS485

Solis S6-EA1P6K-L 6 kW bidirectional AC-coupled inverter for adding 40 to 60 V low-voltage battery storage to grid-connected installations. It includes a single-phase meter and supports up to 125 A charge and discharge current. It has no direct PV input. Dimensions: 440×465×192 mm. Weight: 19.9 kg. IP66 protection and 10-year warranty.

Solis S6-EH3P99.9K10-NV-YD-H 99.9 kW three-phase hybrid inverter for commercial and industrial applications. It features 10 MPPTs / 20 PV inputs, two independent ports for 300 to 950 V high-voltage batteries, backup output and IP66 protection. MPPT range: 150–950 V. Dimensions: 1,174×814×400 mm. Weight: 170 kg. Warranty: 5 years. AFCI 2.0 version. Solis code: 026702150009.

Solis-33K-5G-DC (3 MPPT)

3MPPT three-phase grid inverter (maximum 6 input strings)
Maximum input voltage: 1100V
MPPT voltage range: 200-1000V
Maximum input current: 26A
Maximum efficiency: 98.8%
DC reverse polarity/short circuit/output overcurrent and temperature protection
Protection: IP65
Inverter power: 33kWn

Solis EPM1-5G export power manager for single-phase installations. Controls export via Modbus RS485, supports up to 10 inverters and a communication distance of up to 1,000 m. CT not included.

Features:

Indirect measurement wattmeter, installation without the need to modify the customer's installation
DIN35 rail mounting
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
Ability to use other toroidals with secondary at 5 amps simply by setting the transformation ratio

Solis 30kw 5G Three Phase TRIPLE MPPT DC

3MPPT three-phase grid inverter (maximum 6 input strings)
Maximum input voltage: 1100V
MPPT voltage range: 200-1000V
Maximum input current: 26A
Maximum efficiency: 98.8%
DC reverse polarity/short circuit/output overcurrent and temperature protection
Protection: IP65
Inverter power: 30kWn

Solis S6-EH3P80K10-NV-YD-H 80 kW three-phase hybrid inverter for commercial and industrial applications. It features 10 MPPTs / 20 PV inputs, two independent ports for 300 to 950 V high-voltage batteries, backup output and IP66 protection. MPPT range: 150–950 V. Dimensions: 1,174×814×400 mm. Weight: 170 kg. Warranty: 5 years. AFCI 2.0 version. Solis code: 026702150008.

Solis S6-GR1P3K 3 kW single-phase grid-tied inverter with 2 MPPTs and 2 inputs. Maximum voltage 600 V, MPPT range 90–520 V, IP66 protection and 5-year warranty.

Solis S5-GR3P5K 5 kW three-phase grid-tied inverter with 2 MPPTs / 2 PV inputs, 160 to 1,000 V MPPT range, 180 V start-up voltage, maximum current of 16 A per MPPT and IP66 protection. Dimensions: 310×563×219 mm. Weight: 16.5 kg. Warranty: 5 years. Includes DC switch, MOV surge protection and 4-pin connection. Solis code: 021903230016.

Solis-1P-Meter

Single-phase direct measurement wattmeter
Communication with the inverter via RS485
DIN rail 35
8-bit LCD display
Measuring range (A) : 10(60A)

Solis S6-EH1P10K-L-PLUS 10 kW single-phase hybrid inverter for low-voltage batteries, with backup output and 2 MPPTs. Features a smart port and supports up to 6 units in parallel. Dimensions: 335×560×253 mm. Weight: 24 kg. IP66 protection and 10-year warranty.

Solis S6-GC3P50K04-NV-ND 50 kW three-phase grid-tied inverter with 4 MPPTs / 8 PV inputs, 180 to 1,000 V MPPT range, maximum current of 42 A per MPPT and IP66 protection. Dimensions: 508×612×288 mm. Weight: 35.8 kg. Warranty: 5 years. C5 version. Solis code: 025102010021.

S6-GC3P30K03-NV-ND
Invertor S6 30kW 3Ph, 3 MPPT, DC SW, AFCI 2.0, C5
Marca: Solis
Cod producator: 024902010039
Putere invertor: 30 kWn

Solis S6-GC3P40K04-NV-ND 40 kW three-phase grid-tied inverter with 4 MPPTs / 8 PV inputs, 180 to 1,000 V MPPT range, maximum current of 42 A per MPPT and IP66 protection. Dimensions: 508×612×288 mm. Weight: 34.9 kg. Warranty: 5 years. C5 version with AFCI 2.0. Solis code: 025102010047.

Double crystal module with TOPCon N-Type technology and 495W power.
MC4-EVO2 connectors and 1400mm cable for vertical and horizontal installation.
Black frame and 25-year product warranty.
Measurements 1961 x 1134 x 30 mm.
Pallet: 36 panels
Container: 864 panels

Compact equipment for decentralized systems and large-scale photovoltaic systems due to its high power density.

“Active cooling” with speed-controlled fans ensure optimal
optimal cooling with lower energy consumption, maximizes production
due to temperature reduction

2400V technology, with 2 1200V power stacks in series
Max power of PV generator: 150000 wp
Max input voltage 1000V
Max input current/Max short circuit current: 180 A/325 A
Number of MPP followers: 1
Certificate for Spain and Portugal
5 year warranty
