17kw Hybrid Three Phase Inverter - 4MPPT

Max. input voltage: 1100V
Max. Rated input voltage: 600V
Max. intensity per MPPT: 16A
Maximum efficiency:98.4%
Protection: IP66
10 year warranty

• 12kW single-phase hybrid inverter: 4 MPPT.
• Max. input voltage: 600V.
• Max. Rated input voltage: 350V.
• Maximum efficiency: 98%.
• Protection: IP66, resistant to dust and water.

• 12kW three-phase hybrid inverter: 3 MPPT.
• Max. Input voltage: 1100V.
• Maximum efficiency: 98.4%.
• Protection: IP66, resistant to dust and water.

• 6 kW three-phase hybrid inverter - 2 MPPT
• Max. Input voltage: 1100V
• Max. Rated input voltage: 600V
• Maximum efficiency: 98.4%
• Protection: IP66

• 5 kW three-phase hybrid inverter - 2 MPPT
• Max. Input voltage: 1100V
• Max. Rated input voltage: 600V
• Maximum efficiency: 98%
• Protection: IP66

• 4 kW - 2 MPPT single-phase hybrid inverter
• Max. Input voltage: 1100V
• Max. Rated input voltage: 600V
• Maximum efficiency: 98.4%
• Protection: IP66

• 3 circuit breaker positions reserved for SigenStor or other loads
• 0ms switch to backup mode, worry-free power usage
• 350 ms reverse power flow protection of grid and generator
• Uninterrupted power supply through PV+ESS/grid/generator

• Three-phase power: 10 kW hybrid inverter for residential and commercial use
• Total integration: Combines solar energy, batteries, grid and generator in a single device
• Immediate backup: 0 ms instant changeover for critical loads
• Robust design: Compact, silent and resistant with IP66 protection for outdoors

• 3kW single-phase hybrid inverter: 2 MPPT.
• Max. Input voltage: 1100V.
• Max. Rated input voltage: 600V.
• Maximum efficiency: 98.4%.
• Protection: IP66, resistant to dust and water.

• Three-phase power: 12 kW hybrid inverter for residential and commercial use
• Complete integration: Combine solar energy, batteries, grid and generator in a single device
• Immediate backup: 0 ms instant changeover for critical loads
• Robust design: Compact, silent and resistant with IP66 protection for outdoors

Sigen Gateway HomeMax TP (Three-phase) for 12 inverters

• 3 circuit breaker positions reserved for SigenStor or other loads
• 0ms switch to backup mode, worry-free power usage
• Ready for generator, heat pump or other controllable loads
• Supports whole home backups and partial home backups
• 350 ms reverse power flow protection of grid and generator
• Uninterrupted power supply through PV+ESS/grid/generator

• Rated AC output power: 110 kW (380/400 V, 50/60 Hz)
• Number of MPPT: 8 independent inputs
• MPPT input voltage range: 160–1000 V
• Maximum efficiency: 98.3%

• 3 kW single-phase hybrid inverter: Ideal for medium-sized homes or autonomous systems
• Full integration: Compatible with solar panels, SigenStor batteries and generators
• Automatic backup: Instant (0 ms) switch to backup mode for critical loads
• Robust design: Metal casing, no fans, silent operation (≤25 dB)

● Compact and silent design (25 dB)
● 2 MPPT with high efficiency and flexibility
● IP66 protection and wide thermal range
● Compatible with SigenStor batteries and smart integration

• Rated AC output power: 125kW (400V, 50/60Hz)
• Number of MPPT: 8 independent inputs (2 chains per MPPT)
• MPPT input voltage range: 160–1000V
• Maximum efficiency: 98.6%

• Rated AC output power: 6 kW (380/400 V, 50/60 Hz)
• Number of MPPT: 2 independent inputs
• MPPT input voltage range: 160–1000 V
• Maximum efficiency: 98.6%

• Rated AC output power: 50kW (400V, 50Hz)
• Number of MPPT: 4 independent inputs (2 chains per MPPT)
• MPPT input voltage range: 160–1000V
• Maximum efficiency: 98.6%

• Rated AC output power: 60kW (400V, 50Hz)
• Number of MPPT: 5 independent inputs (2 chains per MPPT)
• MPPT input voltage range: 160–1000V
• Maximum efficiency: 98.6%

• Rated AC output power: 8 kVA (380/400 V, 50/60 Hz)
• Number of MPPT: 2 independent inputs
• MPPT input voltage range: 160–1000 V
• Maximum efficiency: 98.6%

Sigen PV Inverter
Models: 50M1, 60M1, 80M1, 100M1, 110M1

DC input
Max photovoltaic energy CC: 90,000 - 198,000 Wp
Max voltage DC input: 1,100 V
MPPT number: 4 - 8 (depending on model)
Protection

Safety Protection Function: Includes arc fault circuit breaker, DC reverse polarity protection, residual current monitoring, DC/AC type II surge protection, islanding protection, insulation monitoring, and AC overcurrent/overvoltage/short circuit protection.
General data

Measurements (width × height × depth): 918 / 640 / 340 mm
Weight: 68 - 75kg
Operating temperature range: -30 ~ 60 °C
IP protection grade: IP66
Communication: WLAN / Fast Ethernet / RS485 / Sigen CommMod (4G/3G/2G)
