E4 TBB screen

This 4-inch touch monitor is a device to monitor and parameterize the system locally.

Connects to the ComMon port of the inverter to transmit system data to TBB NOVA WEB&APP.
It is recommended to use one on each system, that is, an installation only needs one E4.
It connects to the internet via Wi-Fi. Once it is put into operation, said installation has a 3 or 5 year warranty
depending on the inverter it is connected to.

In a three-phase network self-consumption installation, you have to use E4, plus a three-phase TBB meter.
In an installation, whose connection to the internet is made with Ether-link, you have to put an E4 in the middle of the inverter and Ether-link.

E4 cannot go at the same time with Kinergy II

Radiation sensor compatible with Solar-Log Base and Gateway, it does NOT have connectors for external wind or temperature sensors.

• ezShade 2.0 solar canopy (2 places) in AL6005-T5 aluminum, SUS304 screws, certified, wind resistant up to 50 m/s.
• Integrated drainage with guides and gutters, waterproof.
• Dimensions: 5,500 mm span, 5° inclination, minimum free height 2,100 mm.
• Capacity: up to 6.9 kWp of 460 Wp (3P x 5) or 6.10kWp of 610Wp (2P x 5).

FR Ascent Counterweight Bar 1300

Sigen Gateway C600 for HYB
Supports multiple SigenStor connections for microgrid systems
Seamless backup, worry-free power usage for your business
Generator support, more abundant backup power
350ms standby power flow protection for grid and generator
Uninterrupted power supply through PV+ESS/grid/generator

Three-phase power: 1.6 MW
Instant backup (0 ms)
Supports up to 30 SigenStor batteries
Reverse flow protection (350 ms)

Sigen Energy Gateway HYB-15 Inverter Connection
Cabinet

Sigen Energy Gateway C&I 2000 kW Main Cabinet

Supports multiple Sigen C&I inverter connections for microgrid systems
Seamless switching, guaranteeing 0 ms cut-off on the load side
Integrated bypass circuit for increased system reliability
Compatible with connection to diesel generator and intelligent control
Real-time current monitoring with 350 ms anti-reverse protection

• Immediate backup: 0 ms changeover and continuous supply via PV + ESS / grid / generator
• Compatible with loads and SigenStor: Up to 24 kW and controllable devices (generator, heat pump)
• Advanced protection: Reverse flow 350 ms for network and generator
• Power connections: Supports up to 100 A in AC input, 32 A inverter and optional 14.5 kW generator/load

S6-GR1P6K
S6 6.0kW 1Ph, 2 MPPT, DC SW, Meter Version
Brand: Solis
Manufacturer code: 021801110070
Inverter power: 6kWn

Solis-1P-Meter-CT*1

Single-phase indirect measurement wattmeter
Included open-core toroidals with per-phase measurement capacity of up to 150A and 5 meters of cable
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
DIN35 rail mounting

Solis-S5-3P12K-DC (12 kW - 2 MPPT)

1000V three-phase inverter
It has a maximum input current of 22A
Overvoltage, short circuit, output overcurrent and DC reverse polarity protection
Standard 5-year warranty extendable up to 20 years


Inverter power: 12kWn

Regulator included, ideal for hybrid solar installations.

Compatible with generators, allowing the duration of the reserve to be extended during power outages.

Ability to work in parallel, allowing several inverters to work together as a microgrid.

It has two reserve ports for intelligent control of critical and non-critical loads.

Supports six TOU (time of use) settings to charge and discharge the battery according to the electricity price, optimizing the electricity bill.

Allows 200% overloads for 10 seconds, ideal for consumption peaks.

Supports general settings for lithium batteries, compatible with lead acid batteries.
Inverter power: 5kWn

S6-GR1P4K
S6 4.0kW 1Ph, 2 MPPT, DC SW, Meter Version
Brand: Solis
Manufacturer code: 021801110067
Inverter power: 4kWn

S6-GR1P5K
S6 5.0kW 1Ph, 2 MPPT, DC SW, Meter Version
Brand: Solis
Manufacturer code: 021801110069
Inverter power: 5kWn

S5-GR3P6K
S5 6kW 3Ph Inverter, 2 MPPT, DC SW
Brand: Solis
Manufacturer code: 021903230017
Inverter power: 6kWn

Export Manager 5G (For three-phase systems)

Energy export manager for three-phase systems.
Control power generation and load consumption at all times.
Input voltage: 175~519V (L-L)
Rated voltage: 3/N/PE, 230V / 400V
Monitoring via WiFi/4G/LAN Stick (Optional)
Communication via Modbus (RS485)

Solis-3P-Meter (Direct)

Three-phase direct measurement wattmeter
DIN35 rail mounting
Controls consumption and discharges 0 into the network, and also measures the energy exported to compensate for surpluses.
LCD screen for real-time viewing of measurements
Communication with the inverter via RS485

Solis-EPM1-5G

Energy export manager for single-phase systems
Input voltage: 100~300V (L-N)
Rated voltage: 1/N/PE, 230V
Monitoring via WiFi/4G/LAN Stick (Optional)
Communication via Modbus (RS485)
