Features:

Indirect measurement wattmeter, installation without the need to modify the customer's installation
DIN35 rail mounting
LCD screen for real-time viewing of measurements
Includes as standard 10m of RS485 cable with connector for Solis inverters
Ability to use other toroidals with secondary at 5 amps simply by setting the transformation ratio

Solis S6 GR1P3K (3 kW - 2 MPPT)

2 MPPT Non-Hybrid Single Phase Inverter
Max. input current: 14A
Max. input voltage: 600V
DC reverse polarity protection / against short circuit / over voltage / anti-island and temperature
It has an LCD screen for configuration and visualization of data in real time
5-year warranty (extendable up to 20 years)

Compact equipment for decentralized systems and large-scale photovoltaic systems due to its high power density.

“Active cooling” with speed-controlled fans ensure optimal
optimal cooling with lower energy consumption, maximizes production
due to temperature reduction

2400V technology, with 2 1200V power stacks in series
Max power of PV generator: 150000 wp
Max input voltage 1000V
Max input current/Max short circuit current: 180 A/325 A
Number of MPP followers: 1
Certificate for Spain and Portugal
5 year warranty

Solis S6-GR1P2.5K (2.5 kW - 2 MPPT)

2 MPPT Non-Hybrid Single Phase Inverter
Max. input current: 14A
Max. input voltage: 550V
DC reverse polarity protection / against short circuit / over voltage / anti-island and temperature
It has an LCD screen for configuration and visualization of data in real time
5-year warranty (extendable up to 20 years)

Kit Contents:
20 18º Solarblocs
20 ballasts
16 omegas
16 omega screws
8 end plates for 35 mm frame
8 screws for end plate
24 washers
24 power strips

Rango de temperatura de -40 ° C a + 90 ° C
Máx. Temperatura en el conductor + 120 ° C (20.000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

Dome 6.10 Classic system connection set

Photovoltaic protection panel for 3 inputs + 3 outputs. 1000Vdc, 15A per input, with fuse and fuse base. Enclosure with 18 modules in ABS. MC4 connectors.

Photovoltaic protection panel for 4 inputs + 4 outputs. 1000Vdc, 15A per input, with fuse and fuse base. Enclosure of 2x12 modules in ABS. MC4 connectors.

Photovoltaic protection panel for 8 inputs + 8 outputs. 1000Vdc, 15A per input, with fuse and fuse base. Envelope of 3x18 modules. With MC4 connectors.

Stops power losses
Prevents the PID effect
Measures insulation resistance.
IP56
MC4 connection
Output for 3 MPPT, chains up to 1000V with common negative
3 relay output

Assembly and fire protection system

SUNMETER PRO WIND with LAMINATED solar cell with
SOLAR GLASS and with the same elements as in PV
module. Class A; Modbus RS485 output, Irradiance
Previous ± 2.1%, Previous Temp. ± 0.5°C, wind speed. Houses in
anodized aluminum. With mounting bracket and
Temperature probe input. Accuracy 2.%. service
recalibration after 12/18 months included.

For communication with a pulse anemometer it is necessary:
- 2 x M12 Male 8 pin
- 1 x M12 Y connector for Soluzione anemometer
- 1 x M12 Female 8 pin output to datalogger

Custom photovoltaic protection panel with 4 inputs and 1
outlet with polyester envelope IP66 measurements
H530xW430xD200mm, with 1000Vdc-160A disconnector with
direct drive, 40kA 1000vdc + surge protector
1000vdc 63A NH1 type fuses and fuse holders, connections
with cable gland, assembled and pre-wired

Temperature sensor by modulului will increase the temperature of the solar panourilor spate in Celsius (°C) folosind or PT1000 probe. Probe, folosită pentru măsurarea temperaturii părții din spate a modulului, este plasată între două foi din spate cu lie EVA. This temperature sensor module is compatible with the bottom of the SEVEN temperature sensor.

Main advantage of the sensor is this structure, which is similar to the part in the spate of the photovoltaic module. Mainly, the transfer behavior of heat to the sensor and the photovoltaic module is similar, this is the case.

Part number 3S-MT-PT1000
Senzor tip PT1000
Temperature range -40°C to +85°C
Accuracy ±0.1°C
Rezoluție 0.1°C
Ieșire PT1000
Electrical connection LIYYC11Y PUR Cable of 3 m, resistant to UV rays and intemperii
Operating temperature -40°C to +85°C
Sensor capacity size Ø 35mm x 3mm
Greutate 77 gr
Evaluate IP IP 67
Material capac senzor Foaie din spate laminată (EVA – Tedlar)
Mounting method Autocolant 3m pe spatele panoului
Standardul Class A conform to IEC 60751:2022

M12 Y connector for Soluzione anemometer

Observations:
Photovoltaic inverters and PCS are available from different manufacturers.
Notes:
Project needs: They need a timer to charge or discharge the batteries. The programmer would cause the batteries to be charged at their maximum power, but always limited to the energy they obtain from the photovoltaic (you never want to consume energy from the grid). This time programmer should be able to be manipulated through a website/mobile application. Monitoring is included
Solution proposal: Renlogger in the plant. (Technical room). They have internet connection there (equipment included in the offer). In Renlogger we would set up: GWTCP to collect information from investors
(photovoltaic and bidirectional) On the GWTCP we integrated a specific regulator according to its needs with time control that would send the orders to the bidirectional inverters according to the time and the power produced. Web server with a basic interface (responsive to be able to manage it from your mobile) that allows you to adjust the regulator parameters (and perhaps see instantaneous data from the plant at all times).

• Sigen EV DC 12.5kW VE Charger: Includes 7.5m CCS2 cable for fast and safe charging.
• Max. 12.5kW stable bidirectional charging.
• Ultra-wide range: Full compatibility with VE (150-1000V) and CCS2 connector.
• IP66 protection, maintenance free.

Photovoltaic protection panel with 7 inputs and 7 outputs of 1000vdc with 16A disconnector, 20A fuses in 10x38 and type II surge protection 40kA, 1000vdc. per string, double-insulated polyester hybrid envelope and transparent polycarbonate cover with 720x540x201 gasket, with cable gland, assembled and pre-wired.

Custom photovoltaic protection panel with 9 inputs of which 3 are double and 6 outputs with disconnector, fuse bases and 10x38 1000vdc 16A fuses in IDE IP65 3x18 enclosure in ABS, with wall grommets and cable gland for ground, assembled and pre-wired.
