Huawei Smart Dongle 4G
4G communication and monitoring system for single-phase and three-phase inverters

2001300

MC4 BULKHEAD CONNECTOR 4-6MM²
MC4 surface mount connectors form the interface between an inverter or distributor housing and a string.

MC4 bulkhead connector 4-6mm²
MC4 surface mount connectors form the interface between an inverter housing or PV panel.

Inversor monofásico híbrido nueva generación, 2 MPPT
Eficiencia 97.5%,1-phase, 2 MPPT, Opcional Ethernet and/or 4G via different Dongles, Conector DC Stäubli MC4, Caja de protección IP65, Baterías compatibles LG Chem Resu HV / Huawei LUNA 2000, Dimensiones 36,5 x 36,5 x 14 cm, Peso 12.6kg, Garantía de producto 10 años.

Huawei 2KTL-L1 (2MPPT)

Smart Dongle - WLAN Included
Maximum input voltage: 600V
Maximum intensity by MPPT: 12.5A
Anti-islanding / reverse polarity protection DC / temperature / AC overcurrent, short circuit and overvoltage
Protection: IP65
10 year warranty

Con suministro de voltaje externo de 12 a 28 VCC, cable de 3 m, microprocesador integrado, compensación de temperatura activa, medición de temperatura integrada en la interfaz RS485, con tomas para un sensor de temperatura externo (Pt1000) y un sensor de velocidad del viento externo (conectores no incluidos), protocolo: MODBUS

Fabricante: SMA, 5 años de garantía limitada
Estación de carga de CA monofásica para la carga rápida y fotovoltaica de vehículos eléctricos
en combinación con el Sunny Home Manager 2.0. Configuración de la potencia de carga de 1.3
a 7.4 kW, protección de apagón, función de refuerzo, interruptor de fase automático, enchufe tipo
2, incluye cable de carga de 7.5 m, protección integrada de corriente residual de 6mA CC,
interruptor giratorio, indicador LED de estado, Ethernet / WLAN, SMA Smart Connected.

Huawei BMS (LUNA2000-5KW-C0 - DC/DC Module)
Advanced management system that is responsible for monitoring and controlling the batteries of the power module

Huawei 6KTL-L1

Smart Dongle - WLAN Included
Maximum input voltage: 600V
Maximum intensity by MPPT: 12.5A
Anti-islanding / reverse polarity protection DC / temperature / AC overcurrent, short circuit and overvoltage
Maximum efficiency:98.4%
Protection: IP65
10 year warranty

Huawei 6KTL-M1 HC

Smart Dongle - WLAN-FE Included
Maximum input voltage: 1,100 V
Maximum input current per MPPT: 13.5A
DC reverse polarity / AC overcurrent / short circuit protection, anti-islanding
Protection: IP65
Maximum efficiency: 98.6%
10 year warranty

Huawei 3KTL-M1 HC

Smart Dongle - WLAN-FE Included
Maximum input voltage: 1,100 V
Maximum input current per MPPT: 13.5A
DC reverse polarity / AC overcurrent / short circuit protection, anti-islanding
Protection: IP65
10 year warranty

Maximum voltage: 1500 V
Cable diameter: 5,5 - 9 mm
Cable cross section: 4 -6 mm2

Maximum voltage: 1500 V
Cable diameter: 5,5 - 9 mm
Cable cross section: 4 -6 mm2

Temperature range -40 ° C to + 90 ° C
Max. conductor temperature + 120 ° C (20,000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

Temperature range -40 ° C to + 90 ° C
Max. conductor temperature + 120 ° C (20,000 h)
Nominal voltage U0 / UAC1.0 / 1.0 kVDC 1.5 / 1.5 kV
Weather and UV resistance

Temperature range -40 ° C to + 90 ° C
Max. conductor temperature + 120 ° C (20,000 h)
Nominal voltage U0 / U AC1.0 / 1.0 kV DC 1.5 / 1.5 kV
Weather and UV resistance

Temperature range - 40 °C to + 90 °C (for fixed and flexibleinstallation)
Max. Temperature at conductor + 120°C (20.000 h, 50 % residual elongation)
Rated voltage U0/U AC 1,0 / 1,0 kV DC 1,5 / 1,5 kV
Resistance weather-resistant and UV-resistance
