North solar PARKING structure with capacity for 2 spaces, galvanized finish without roof sheet
3 Kits 01V5 K2 singlerail structure
Capacity for 15 panels between 1m-1.13m x 2.1m-2.3m

Stops power losses
Prevents the PID effect
Measures insulation resistance.
IP56
MC4 connection
Output for 3 MPPT, chains up to 1000V with common negative
3 relay output

SUNMETER PRO WIND with LAMINATED solar cell with
SOLAR GLASS and with the same elements as in PV
module. Class A; Modbus RS485 output, Irradiance
Previous ± 2.1%, Previous Temp. ± 0.5°C, wind speed. Houses in
anodized aluminum. With mounting bracket and
Temperature probe input. Accuracy 2.%. service
recalibration after 12/18 months included.

For communication with a pulse anemometer it is necessary:
- 2 x M12 Male 8 pin
- 1 x M12 Y connector for Soluzione anemometer
- 1 x M12 Female 8 pin output to datalogger

Trina 575Wp TSM-DE19R VERTEX

Custom photovoltaic protection panel with 4 inputs and 1
outlet with polyester envelope IP66 measurements
H530xW430xD200mm, with 1000Vdc-160A disconnector with
direct drive, 40kA 1000vdc + surge protector
1000vdc 63A NH1 type fuses and fuse holders, connections
with cable gland, assembled and pre-wired

Temperature sensor by modulului will increase the temperature of the solar panourilor spate in Celsius (°C) folosind or PT1000 probe. Probe, folosită pentru măsurarea temperaturii părții din spate a modulului, este plasată între două foi din spate cu lie EVA. This temperature sensor module is compatible with the bottom of the SEVEN temperature sensor.

Main advantage of the sensor is this structure, which is similar to the part in the spate of the photovoltaic module. Mainly, the transfer behavior of heat to the sensor and the photovoltaic module is similar, this is the case.

Part number 3S-MT-PT1000
Senzor tip PT1000
Temperature range -40°C to +85°C
Accuracy ±0.1°C
Rezoluție 0.1°C
Ieșire PT1000
Electrical connection LIYYC11Y PUR Cable of 3 m, resistant to UV rays and intemperii
Operating temperature -40°C to +85°C
Sensor capacity size Ø 35mm x 3mm
Greutate 77 gr
Evaluate IP IP 67
Material capac senzor Foaie din spate laminată (EVA – Tedlar)
Mounting method Autocolant 3m pe spatele panoului
Standardul Class A conform to IEC 60751:2022

Circutor Network Analyzer CVM-E3-MINI-MC-485-IC ref. M56454.

Electric vehicle charging protection panel according to ITC-BT-52.
2 Poles, 32A, POP 50:550 permanent and transient overvoltage protection.

Electric vehicle charging protection panel according to ITC-BT-52.
2 Poles, 40A, POP 50:550 permanent and transient overvoltage protection.

Electric vehicle charging protection table according to ITC-BT-52.
4 Poles. 32A, POP 50:550 permanent and transient overvoltage protection.

Electric vehicle charging protection panel according to ITC-BT-52.
4 Poles. 40A, POP 50:550 permanent and transient overvoltage protection.

Sigenergy 12.5 kW bidirectional DC fast-charging module with an integrated 7.5 m CCS2 cable. Compatible with electric vehicles from 150 to 1,000 V, with IP66 protection, intelligent cooling and remote control through the mySigen App. Requires a Sigen Energy Controller.

EBick plinth with wheels that allows modules to be stacked up to 3 heights.
Recommended for small spaces where use is not possible
of pallet truck.

1000Vdc, 15A per input, with
fuse and fuse base + surges 40kA 1000vdc.
Enclosure of 3x18 modules. Box without drilling and with
stuffing box inside.

[MD00138] BV2M-40/240 - Single-phase surge protectors Type 2
• Maximum service voltage Uc = 275 V. Protection level [N-T] Up = 1.2 kV. Maximum discharge current (8/20) Imax = 40 kA. Mounting on DIN rail, pluggable, width 1 module (18mm).

Measurements (H×W×D): 90×18×68 mm
Weight: 0.13kg
Technical source: MD Technological Equipment - BV2M-40/240 technical sheet

Temperature Sensor Module, PT1000 with output
analog,
Measuring range: -40°C to +85°C
Power supply 12...30 V DC
4-20mA output
Accuracy: ±0.1°C
Housing: Plastic housing with aluminum plate, H x
W x L: 12mm x 50mm x 50mm
3 m PUR cable, UV and weather resistant
The Class A Standard according to IEC 60751:2022

Photovoltaic protection panel with 7 inputs and 7 outputs of 1000vdc with 16A disconnector, 20A fuses in 10x38 and type II surge protection 40kA, 1000vdc. per string, double-insulated polyester hybrid envelope and transparent polycarbonate cover with 720x540x201 gasket, with cable gland, assembled and pre-wired.

Protection box
photovoltaic with 16 inputs and 16 outputs, mounted on a plate
800x600x300mm IP66 polyester cabinet with door
opaque Composed of 32 fuse bases and fuses
10x38 15A 1kV + surge protection BF3-
40/1000vdc with bulkhead, assembled and pre-wired.

Custom photovoltaic protection panel with 9 inputs of which 3 are double and 6 outputs with disconnector, fuse bases and 10x38 1000vdc 16A fuses in IDE IP65 3x18 enclosure in ABS, with wall grommets and cable gland for ground, assembled and pre-wired.
