Sigenergy Sigen Gateway C60-2 (11110050)

Sigenergy Sigen Gateway C60-2 (11110050)

https://pnp.energy/web/image/product.template/6398/image_1920?unique=cde301f Sigenergy P&P4294

Sigen Gateway C60-2 Compatible con múltiples conexiones SigenStor para sistemas de micro-red. Conmutación automática sin interrupción (0 ms en el lado de la carga). Circuito de bypass integrado para mayor fiabilidad del sistema. Soporta conexión a generador diésel con control inteligente. Monitoreo de corriente en tiempo real con protección anti-retroceso de 350 ms.

Not Available For Sale

  • Marca

This combination does not exist.

Contact Us
Marca: Sigenergy
Technical guide

Compatibility and configuration

Key data for the Sigen Gateway C60-2, a three-phase Gateway for SigenStor backup and microgrids.

Grid
Three-phase · 380/400 V · 91,2 A
Nominal power
60 kW
Backup switchover
0 ms under the stated test conditions
Inverter ports
2 connections · 45.6 A maximum per input
Generator port
380/400 V · up to 60 kW
Protection
IP54 · overvoltage category III
Communication
Fast Ethernet, RS485 and dry contact
Installation and temperature
Wall-mounted · -30 to 55 °C
Weight
35 kg according to the family data sheet

Technical frequently asked questions

How many inverters can it connect?

It provides 2 inverter ports, with a maximum of 45.6 A per input according to the data sheet.

Does it support a generator?

Yes. It includes a smart generator port; control, starting and protection must follow the manufacturer diagram.

What is required for 0 ms switchover?

It requires the Gateway, Sigen Energy Controller and Sigen Battery, with available power above the backed-up loads under the stated conditions.

Official sources published on this product page: data sheet. Specifications are subject to the conditions in the linked documents. Data sheets for this family may be preliminary and show different revisions.
