Sigenergy Sigen Gateway C180-9 (180kW) (11110026)
Sigenergy P&P4081• Alta capacidad: Soporta hasta 9 inversores. • Compatible con almacenamiento: Funciona con SigenStor, generadores y EV. • Seguridad: Flujo inverso 350 ms y respaldo 0 ms. • Energía ininterrumpida: Suministro continuo vía PV + ESS / red / generador.
| Marca: Sigenergy |
| warranty: 10 años |
Compatibility and configuration
Official data for Sigen Gateway C180-9: C&I gateway for microgrid and three-phase backup
Grid
Three-phase · 380-400 V · 50/60 Hz
Power
180 kW nominal
Current
274 A nominal
Backup
180 kW · 0 ms transfer
Inverter ports
9
Generator
Supported · 2-wire start
Communication
Fast Ethernet · RS485 · dry contact
Dimensions
800 × 2.300 × 830 mm
Weight
345 kg
Technical frequently asked questions
What is its function?
It switches and coordinates grid, backup, inverters and generator.
Which system is it compatible with?
It integrates with expressly compatible Sigen C&I equipment.
What must be checked before installation?
Check power, ports, grid, generator, cable sizes, protection and communications.
Official sources published on this product page: data sheet. Specifications are subject to the conditions in the linked documents.
