SPF 2/2-40/1000/15 (221) Photovoltaic protection panel for 2 inputs + 2 outputs
P&P2912Cuadro de protección fotovoltaico para 2 entradas + 2 salidas. 1000Vcc, 15A por entrada, con fusible y base de fusible. Envolvente de 12 módulos en ABS. Conectores MC4.
Compatibility and configuration
Official data for SPF 2/2-40/1000/15 (223) + AC2-25/SP: values for the documented protection box; the existing commercial name states variant 221
Documented model
SPF 2/2-40/1000/15 (223) + AC2-25/SP
PV inputs
2
Outputs
2
Voltage
1.000 Vcc
Fuse
15 A
SPD
Type 2 · EN 61643-11
Maximum discharge
40 kA · 8/20 µs
AC output
230 Vac · 5.7 kVA
Protection
IP65
Technical frequently asked questions
What is its function?
It protects two PV strings against overcurrent and surges and includes AC protection.
Which system is it compatible with?
The attached sheet documents variant 223 + AC2-25/SP; confirm equivalence with commercial variant 221.
What must be checked before installation?
Check variant, inputs, outputs, polarity, voltage, fuses, SPD, AC protection and torque.
Official source published on this product page: data sheet. Specifications are subject to the conditions in the linked document. The source does not publish an unambiguous weight for this reference; Product.weight is omitted.
