Atmoce AC Connection Base for M‑ELV BattBank 16 kWh
Atmoce P&P4651Base de conexión AC Atmoce para BattBank M‑ELV 16 kWh en aplicaciones comerciales e industriales.
| Marca: Atmoce |
| warranty: 12 años |
Compatibility and configuration
Official data for MS-ACCB-CNI: AC connection base for M-ELV BattBank C&I
Documented model
MS-ACCB-CNI
Component
AC connection base
System
M-ELV BattBank · C&I
Dimensions
880 × 220 × 483 mm · W × H × D
Protection
IP66
Cable
35-50 mm²
Installation
Base of floor-mounted stack
Spacing
More than 350 mm between adjacent clusters
Official weight
35 kg
Technical frequently asked questions
What is its function?
It integrates the AC connection at the base of an M-ELV BattBank stack.
Which system is it compatible with?
It is the MS-ACCB-CNI component of the M-ELV BattBank architecture for C&I applications.
What must be checked before installation?
Check cable cross-section, support, IP66 rating, inter-stack clearances and system configuration.
Official source published on this product page: data sheet. Specifications are subject to the conditions in the linked document.
