Sigenergy Sigen Power Sensor TP-CT120-DH (medida indirecta) (1426000007)

Sigenergy Sigen Power Sensor TP-CT120-DH (medida indirecta) (1426000007)

https://pnp.energy/web/image/product.template/6450/image_1920?unique=36b4b46 Sigenergy P&P4347

Sigen Power Sensor se integra perfectamente con los dispositivos Sigenergy, sin necesidad de configuración. Este sensor de potencia forma parte del sistema de almacenamiento de energía 5 en 1 de SigenStor. El ESS de Sigenergy integra a la perfección el inversor fotovoltaico, el sistema de conversión de energía de la batería (PCS), el cargador de CC EV para vehículos eléctricos, el paquete de baterías y el sistema de gestión de energía (EMS).

Not Available For Sale

  • singlephase/threephase
  • Marca
  • warranty

This combination does not exist.

Contact Us
singlephase/threephase: Trifásico
Marca: Sigenergy
warranty: 2 años
Technical guide

Compatibility and configuration

Official data for Sigen Sensor TP-CT120-DH: three-phase meter with external current transformers

Reference
TP-CT120-DH
Grid
3P3W / 3P4W · 173-480 Vca · 50/60 Hz
Current transformers
3 external CTs · 120 A · 16 mm aperture
Accuracy
Voltage 0.5% · current 0.5% · power 1%
Communication
RS485 · Modbus RTU · 9.600 bps
Dimensions
72 × 94,5 × 65 mm
Published weights
Meter 0,20 kg · each CT 0,09 kg
Protection
IP51
Installation
35 mm DIN rail

Technical frequently asked questions

What is its function?

It measures a three-phase grid through three external CTs.

Which system is it compatible with?

It is used with Sigenergy controllers and the specified CTs.

What must be checked before installation?

Check CT ratio and direction, 3P3W/3P4W grid, RS485 and Modbus.

Official sources published on this product page: data sheet · installation manual. Specifications are subject to the conditions in the linked documents. The source publishes meter and per-CT weights separately, not the total set weight; Product.weight is omitted.
