Solis S6-GC100K (100 kW, three-phase grid-tied, USB, without AFCI, 024301110034)

Inversor trifásico de 100 kW ideal tanto para nuevas instalaciones como para revamping. Entrada DC: 1100 V máx., 10 × 36 A, 10 MPPT / 20 strings Eficiencia máx.: 98,7% Protecciones integradas: polaridad inversa, cortocircuito, sobretemperatura y sobretensiones Tipo II en AC/DC Grado de protección: IP66, refrigeración inteligente Garantía: 5 años (ampliable hasta 20)

Power (Wn)
singlephase/threephase
Function
Nº of MPPTs
MPPT voltage range (V)
MPPT maximal current (A)
Inverter / solar panel / Battery
starting voltage(V)
Marca
output voltage(v)
warranty
Número de strings FV

This combination does not exist.

Power (Wn): 100 K

singlephase/threephase: Trifásico

Function: No híbrido

Nº of MPPTs: 10-20

MPPT voltage range (V): 160-1000

MPPT maximal current (A): 42

Inverter / solar panel / Battery: Inversor

starting voltage(V): 180

Marca: Solis

output voltage(v): 400V

warranty: 5 años

Número de strings FV: 20

Documents

Solis_S6-GC(80-125)K_Certificado_NTS631_ES.pdf

Solis_S6-GC(80-125)K_Ficha_tecnica_ES.pdf

Solis_datasheet_S6-GC(100-125)K_IND_V1,3_202505.pdf

Technical guide

Compatibility and configuration

Key data for the Solis S6-GC100K high-power three-phase grid-tied inverter.

AC output

100 kW nominal · 110 kVA maximum

Grid

3/N/PE · 220/380 or 230/400 V · 152/144.3 A

PV input

1,100 V maximum · MPPT 160-1,000 V

MPPT and strings

8 MPPT · 16 strings · 4 × (42 A / 36 A)

Efficiency

98.7% maximum · 98.3% EU

Protection

Type II DC/AC · string monitoring · optional AFCI/PID

Enclosure and temperature

IP66 · -30 to 60 °C · smart fan cooling

Communication

RS485 · optional Wi-Fi, GPRS and PLC

Weight

93 kg

Technical frequently asked questions

How many strings does it support?

The 100K version has 8 MPPT and up to 16 strings, with four input groups according to the data sheet.

Does it include AFCI?

The data sheet lists AFCI as optional, as is PID recovery. Confirm the exact configuration before ordering.

What conductor size does the AC terminal support?

The data sheet specifies an OT terminal up to 240 mm². Final sizing depends on current, temperature, grouping and regulations.

Official sources published on this product page: data sheet. Specifications are subject to the conditions in the linked documents.

AC-side storage option

Add Atmoce storage without replacing this inverter

In grid-connected installations with a compatible architecture, Atmoce storage can be added on the AC side.

ResidentialAtmoce MS-7K-U · 7 kWh

For homes and small professional projects.

Commercial and industrialAtmoce MS-16K-U · 16 kWh

For C&I projects that require a higher-capacity solution.

Important: The integration is AC-coupled: it does not imply connection to the battery port or direct DC compatibility. Phases, metering/EMS, backup, protection and system topology must be validated before quoting.
