  3. Sigenergy SigenStack BAT 12 (12kWh) (11130014)
Distribuidor Especialista

Sigenergy SigenStack BAT 12 (12kWh) (11130014)

https://pnp.energy/web/image/product.template/5960/image_1920?unique=7fc36a9 Sigenergy P&P3871

• Alta densidad: 12 kWh/módulo, hasta 253 kWh/sistema • Seguridad: IP66, supresión de incendios y control térmico de celdas • Compatible y escalable: Integración CAN con los inversores Sigenergy, 4‑21 módulos • Instalación rápida: Montaje en suelo, refrigeración por aire, puesta en marcha simple

Not Available For Sale

  • Power (Wn)
  • Marca
  • warranty
  • Inverter / solar panel / Battery

This combination does not exist.

Contact Us
Power (Wn): 12 kWh
Marca: Sigenergy
warranty: 10 años
Inverter / solar panel / Battery: Batería
Technical guide

Compatibility and configuration

Technical configuration of the SigenStack BAT 12.0 for commercial and industrial storage.

Energy per module
12.06 kWh total
System configuration
4-21 modules per system · up to 7 per stack
Maximum capacity
Up to 253 kWh per system
Compatible inverter
Sigen C&I Hybrid Inverter series · CAN communication
Charge and discharge
0.5C nominal · 1C maximum
Safety
Aerosol, smoke sensor and exhaust system
Protection and temperature
IP66 · operation from -20 to 55 °C
Cooling and monitoring
Smart air cooling · mySigen app
Weight
105 kg per module

Technical frequently asked questions

How does the SigenStack BAT 12.0 scale?

Each module provides 12.06 kWh. The system supports 4 to 21 modules, with up to 7 per stack and up to 253 kWh.

Which inverter is compatible?

The data sheet specifies compatibility with the Sigen C&I Hybrid Inverter series through CAN communication.

How is it installed?

It is a floor-mounted C&I system. Configuration and commissioning must follow the official manual and be carried out by qualified personnel.

Official sources published on this product page: data sheet · installation manual. Specifications are subject to the conditions in the linked documents.
