Solis-EPM3-5G
Solis P&P2054Export Manager 5G (Para sistemas trifásicos) Gestor de exportación de energía para sistemas trifásicos. Controla la generación de energía y el consumo de la carga en todo momento. Voltaje de entrada: 175 ~ 519 V (L-L) Voltaje nominal: 3/N/PE, 230 V / 400 V Monitorización a través de WiFi/4G/LAN Stick (Opcional) Comunicación a través de Modbus (RS485)
| Marca: Solis |
| warranty: 2 años |
Compatibility and configuration
Official data for Solis EPM3-5G: three-phase export power manager for up to ten inverters
Grid
400 V · 3/N/PE or 3/PE
Range
100-277 V L-N · 176-480 V L-L
Frequency
45-65 Hz
Communication
Modbus RS485
Inverters
Up to 10 Solis
Control accuracy
3%
Control time
5 s
Dimensions
364 × 276 × 114 mm
Weight
2.1 kg
Technical frequently asked questions
What is its function?
It controls export and monitors generation and consumption.
Which system is it compatible with?
It integrates by RS485 with up to ten compatible Solis inverters.
What must be checked before installation?
Check grid, current transformers, polarity, RS485 and configuration.
Official sources published on this product page: data sheet. Specifications are subject to the conditions in the linked documents.
