SPVE 2-40/L (for VE chargers up to 7.4 kW)
P&P3549Cuadro de protección recarga de vehículos eléctricos acorde ITC-BT-52. 2 Polos, 40A, protección sobretensiones permanentes POP 50:550 y transitorias.
Compatibility and configuration
Official data for SPVE 2-40/L: protection board for an electric-vehicle charging station
Grid
Single-phase
Power
9.2 kVA
Current
40 A · 230 Vca
Circuit breaker
2 poles · C curve · 10 kA
RCD
2 poles · 40 A · 30 mA Type A
Surge protection
Type 2 · 15 kA
Protection
ABS · IP65
Dimensions
6 DIN · 231 × 202 × 113 mm
Weight
1.7 kg
Technical frequently asked questions
What is its function?
It protects the installation against the documented electrical risks.
Which system is it compatible with?
Size it to the grid, protected equipment and data-sheet topology.
What must be checked before installation?
Check voltage, current, poles, protection, conductor size and torque.
Official sources published on this product page: data sheet. Specifications are subject to the conditions in the linked documents.
