• Main controller of SigenStack tower: coordinates and manages all battery modules
• Optimizes charging, discharging, and module balancing for efficiency and lifespan
• Maximum capacity managed per tower: 252 kWh

Tensiune 48 V (45….53,5 Vdc)
Putere disponibilă 90% (3,2 kW)
Descărcare recomandată 37 A (1,7 kW)
Descărcare maximă 74 A (3,5 kW)
Conexiune Can-Bus și RS485
Compatibil cu Victron și Solis
> 6000 de cicluri de viață la 25ºC (15 ani)
Dimensiuni: 442mm x 420mm x 132mm
Greutate: 32 kg.

The TCC-CAN control module for Cegasa's eBick Ultra 175 modular battery.
The BMS, through CAN communication, allows sending the most relevant battery data such as SOC, temperature, alarms, current and voltage both in charge and discharge, among others. In addition, with the eViewer App, via Bluetooth connection, it allows to visualize the module parameters such as battery SOC, cycles and bus voltage, among others.

BF100 este un dulap pentru baterii DC montabil în exterior, cu design inteligent de răcire cu aer. Oferă o capacitate flexibilă a unui singur cabinet de 100 kWh.

50kW/100kWh
Invertor hibrid Solis S6-EH3P50K-H

Putere nominală: 50 kW trifazat.
Putere fotovoltaica maxima recomandata: 100 kW.
4 MPPT cu până la 8 șiruri PV.
Tensiune fotovoltaică maximă: 1000 V, interval MPPT 150–850 V.
Curent maxim de intrare: 4 × 40 A.
Suportă încărcarea/descărcarea bateriei până la 55 kW (140 A în paralel).
Treceți la backup < 10 ms cu putere de rezervă completă (50 kW).
Eficiență maximă: 97,8% (98,5% la încărcarea bateriei de la PV).
Protecție avansată: IP66, anti-insulă, supratensiune de tip II, scurtcircuit, polaritate inversă, AFCI opțional.
Comunicare: CAN / RS485 / Ethernet (Wi-Fi și 4G opțional).

Baterie Dyness BF100
Capacitate utila: 100 kWh.
Tehnologie: LiFePO₄ (LFP) sigur și durabil.
Tensiune nominală: 768 V (domeniu de funcționare 680–864 V).
Putere de descărcare continuă: 50 kW (0,5 C).
Durata de viață: 6000+ cicluri @ 90% DOD.
Design modular în rack standard de 19 inchi, scalabil până la MWh.
Sistem inteligent BMS cu comunicare CAN/RS485.
Nivel de protectie IP55
Certificari internationale: CE, IEC 62619, UN38.3.

SigenStack Battery Controller M1 - 0.5C
This is the main controller for the battery modules in the SigenStack series. Its function is to regulate and optimize the performance of the energy storage system in each tower, enabling efficient management of the stored energy. The maximum capacity that can be installed per tower controller is 252 kWh.

The eBick Ultra 175 is Cegasa's answer to installers looking for a pre-installed, self-managing, plug-and-play battery.
It is ideal for replacing lead-acid batteries in existing installations, as well as for new self-consumption and off-grid
off-grid and self-consumption installations with requirements between 13 and 54 KWh.
The eBick Ultra 175, offering an IP30 degree of protection, is stackable up to 2 heights and up to 8 parallel connections in controlled conditions for communication.

Gama de tensiune: 572 - 689V
Tensiune nominală: 634V
Putere nominala: 33 kW

The SigenStack cover serves as protection for the battery modules inside the tower. Its main function is to safeguard the modules from external elements such as dust, moisture, and adverse environmental conditions, helping to extend the system’s lifespan and maintain installation safety.
