Sigen PV Inverter
Models: 50M1, 60M1, 80M1, 100M1, 110M1

DC input
Max photovoltaic energy CC: 90,000 - 198,000 Wp
Max voltage DC input: 1,100 V
MPPT number: 4 - 8 (depending on model)
Protection

Safety Protection Function: Includes arc fault circuit breaker, DC reverse polarity protection, residual current monitoring, DC/AC type II surge protection, islanding protection, insulation monitoring, and AC overcurrent/overvoltage/short circuit protection.
General data

Measurements (width × height × depth): 918 / 640 / 340 mm
Weight: 68 - 75kg
Operating temperature range: -30 ~ 60 °C
IP protection grade: IP66
Communication: WLAN / Fast Ethernet / RS485 / Sigen CommMod (4G/3G/2G)

• High capacity: Supports up to 9 inverters.
• Storage Compatible: Works with SigenStor, generators and EVs.
• Security: Reverse flow 350 ms and backup 0 ms.
• Uninterrupted power: Continuous supply via PV + ESS / grid / generator.

• Rated AC output power: 80kW (400V, 50Hz)
• Number of MPPT: 6 independent inputs (2 chains per MPPT)
• MPPT input voltage range: 160–1000V
• Maximum efficiency: 98.6%

Modular electric energy meter that displays power (kWh, kVArh and kVA) and other measurements directly on its backlit LCD screen.
It has been designed for three-phase load measurement with connection via CT and is suitable for applications up to 12000 A.

VE.Can to CAN-bus BMS type B Cable 5m

Solution model: Solis + Dyness 50kW/100kWh
Inverter: Solis S6-EH3P50K-H
Inverter rated power: 50 kW three-phase
Recommended PV power: Up to 100 kW
Battery: Dyness BF100
Useful capacity: 100 kWh
Battery technology: LiFePO4
Application: Commercial/industrial storage.

Sigen Energy Gateway C&I 600 kW

Compatible with up to 30 SigenStor inverters connected in parallel
3 circuit breaker positions reserved for SigenStor or other loads
0 ms switch to backup mode for uninterrupted power use
Prepared for connection of generator, heat pump or other controllable loads
350 ms anti-reverse protection against mains and generator
Uninterrupted power supply via PV + ESS/grid/generator

• High capacity: Up to 50 kW and 50 inverters.
• Storage Compatible: Works with SigenStor, generators and EVs.
• Security: Reverse flow 350 ms and backup 0 ms.
• Uninterrupted Power: Supply through PV + ESS / grid / generator.

The Victron EM24 Ethernet is a standard device for measuring the power and energy of a three-phase application, for example at the distribution box or for measuring the output of a PV inverter, AC generator or inverter or inverter/charger.

• ezShade 2.0 solar canopy (2 places) in AL6005-T5 aluminum, SUS304 screws, certified, wind resistant up to 50 m/s.
• Integrated drainage with guides and gutters, waterproof.
• Dimensions: 5,500 mm span, 5° inclination, minimum free height 2,100 mm.
• Capacity: up to 6.9 kWp of 460 Wp (3P x 5) or 6.10kWp of 610Wp (2P x 5).

Sigen Gateway C600 for HYB
Supports multiple SigenStor connections for microgrid systems
Seamless backup, worry-free power usage for your business
Generator support, more abundant backup power
350ms standby power flow protection for grid and generator
Uninterrupted power supply through PV+ESS/grid/generator

Three-phase power: 1.6 MW
Instant backup (0 ms)
Supports up to 30 SigenStor batteries
Reverse flow protection (350 ms)

Intelligent load distribution and backup cabinet
Manage critical and non-critical loads automatically
Instant changeover (0 ms) in case of blackout
Up to 60 kW capacity in smart charging

Sigen Energy Gateway HYB-15 Inverter Connection
Cabinet

EWS-5Y INV SP2 2-6 – 5-year warranty extension Sigen Hybrid SP2 (2–6kW) (41010066)

EWS-5Y INV TP2 3-12 – 5-year warranty extension Sigen Hybrid TP2 (3–12kW) (41010067)

Sigen Energy Gateway C&I 2400 kW Smart Load Cabinet

Sigen Energy Gateway C&I 2000 kW Main Cabinet

Supports multiple Sigen C&I inverter connections for microgrid systems
Seamless switching, guaranteeing 0 ms cut-off on the load side
Integrated bypass circuit for increased system reliability
Compatible with connection to diesel generator and intelligent control
Real-time current monitoring with 350 ms anti-reverse protection

S6-GR1P6K
S6 6.0kW 1Ph, 2 MPPT, DC SW, Meter Version
Brand: Solis
Manufacturer code: 021801110070
Inverter power: 6kWn
