SPVE 2-32/ML (with resettable Aut. for VE chargers up to 7.4 kW)
P&P3961Cuadro de protección recarga de vehículos eléctricos acorde ITC-BT-52. 2 Polos, 32A, protección sobretensiones permanentes POP 50:550 y transitorias. Automático rearmable
Compatibility and configuration
Official data for SPVE 2-32/MLT: auto-reclosing single-phase EV charging protection board
Power
7.3 kVA · 230 Vac
Current
32 A
Circuit breaker
2 poles · C curve
RCD
40 A · 30 mA Type A
Reclosing
3 s
Undervoltage
<160 Vca
Surge protection
Type 2 · 15 kA
Dimensions
6 DIN · 231 × 202 × 113 mm · IP65
Weight
2 kg
Technical frequently asked questions
What is its function?
It protects the installation against the documented electrical risks.
Which system is it compatible with?
Size it to the grid, protected equipment and data-sheet topology.
What must be checked before installation?
Check voltage, current, poles, protection, conductor size and torque.
Official sources published on this product page: data sheet. Specifications are subject to the conditions in the linked documents.
