Including cable (approx. 140 cm) and TS4 connector system
Robust anodized aluminum frame
High quality solar cells
Version with 10 busbars
rated power 510
rated voltage 43.00
current ratet 11.75
power tolerance +5 Wp
plug type MC4EVO2
L*W*H (mm) 2187 * 1102 * 35
short circuit current 12.35
open circuit current 51.90
Maximum system voltage 1500
cell type monocrystalline
Number of cells 150
Weight (kg): 26.50
31 unit per pallet

• 3 breaker positions reserved for SigenStor or other loads.
• Switch to backup mode in 0 ms, uninterrupted energy use.
• Reverse power flow protection of 350 ms from grid or generator.
• Uninterrupted power supply via PV+ESS/grid/generator.

Sigen Gateway HomeMax TP (Three-phase) for 12 inverters

3 breaker positions reserved for SigenStor or other loads
0 ms switchover to backup mode, worry-free energy use
Ready for generator, heat pump, or other controllable loads
Supports whole-home and partial-home backup
350 ms reverse power flow protection from grid and generator
Uninterrupted power supply via PV+ESS/grid/generator

The Cerbo GX is a flexible communication centre that will take remote monitoring to the next level. With all the hardware connection possibilities to fit your every need.

Potencia nominal: 110000W
12 seguidores MPP independientes.
Sin display.
IP 65.
Potencia máx. del generador fotovoltaico:165000 Wp STC
Tensión de entrada máx.1100 V
Rango de tensión del seguidor del MPP/tensión asignada de entrada: De 500 V a 800 V/ 585 V
Tensión de entrada mín./de inicio200 V/250 V
Corriente máx. de entrada/por seguidor del MPP: 26 A/40 A
Número de entradas de seguidores del MPP independientes/Strings por entrada de seguidores del MPP: 12/2

25kw three-phase inverter hybrid- 4MPPT

Max. input voltage: 1100V
Max. Rated input voltage: 600V
Max. intensity per MPPT: 16A
Maximum efficiency:98.4%
Protection: IP66
10 year warranty

• IP66 protection rating, more reliable
• Plug & play, easy to use
• Support 2G / 3G / 4G communication

• Dynamic charging 11 kW with integrated RCD.
• Automatic power adjustment to prevent overloads.
• IP65 mounting on wall or pole, Type 2 AC connector.

Sigen PV Inverter
Modelos: 50M1, 60M1, 80M1, 100M1, 110M1

Entrada de CC
Energía fotovoltaica máx. CC: 90,000 - 198,000 Wp
Tensión máx. de entrada de CC: 1,100 V
Número de MPPT: 4 - 8 (dependiendo del modelo)
Protección

Función de Protección de Seguridad: Incluye interruptor de circuito de falla de arco, protección contra polaridad inversa en CC, monitorización de corriente residual, protección contra sobretensiones en CC/CA tipo II, protección contra isla, monitorización de aislamiento, y protección contra sobrecorriente/sobretensión/cortocircuito en CA.
Datos generales

Medidas (ancho × alto × prof.): 918 / 640 / 340 mm
Peso: 68 - 75 kg
Rango de temperatura de funcionamiento: -30 ~ 60 °C
Grado de protección IP: IP66
Comunicación: WLAN / Fast Ethernet / RS485 / Sigen CommMod (4G/3G/2G)

Backup Box-B0 Huawei

Rated voltage: 220V / 230V
AC output voltage range: 198V - 253V
Maximum output current: 22.7
Protection: IP65

25 años garantía producto / 30 años de garantía de producción
Fabricante Europeo
1910 x 1134 x 35 mm

Huawei BATERÍA 5kWh

Maximum power output. 2.5kw
Rated voltage (single phase system): 360V
Rated voltage (single phase system): 600V
Cell Technology: Lithium-Ferrophosphate(LiFePO4)
Protection: IP66
10 year warranty

70A MPPT solar charge controller for battery systems of 12, 24, 36 or 48 volts and up to 250V photovoltaic field, Victron Energy brand SmartSolar MPPT 250/70-Tr VE.Can (with connection for solar input with screw).

70A MPPT solar charge controller for 12, 24, 36 or 48 volt battery systems and up to 250V PV field, Victron Energy SmartSolar MPPT 250/70-MC4 model.
The VE.Can communications system allows connecting and synchronizing multiple controllers (up to 25 controllers) in an installation.

Solis Híbrido S6-EH3P10K-H (medidor incluido)

2 MPPT Hybrid Single Phase Inverter
Maximum input voltage: 1000 V
Maximum input current: 16 A / 16 A
Maximum efficiency: 96.5%
DC reverse polarity protection / output over current / short circuit and over voltage
Protection level: IP65
5 year warranty extendable up to 20 years

• ezShade 2.0 solar canopy (2 spaces) in AL6005-T5 aluminum, SUS304 fasteners, certified, wind-resistant up to 50 m/s.
• Integrated drainage with guides and gutters, waterproof.
• Dimensions: 5,500 mm span, 5° tilt, minimum free height 2,100 mm.
• Capacity: up to 15.3 kWp of 510 Wp (3P x 10) or 11.8 kWp of 590 Wp (2P x 10).

• Single-phase hybrid inverter 8 kW - 2 MPPT
• Max. input voltage: 600 V
• Max. rated input voltage: 350 V
• Maximum efficiency: 98%
• Protection: IP66

• Single-phase hybrid inverter 10 kW: 2 MPPT.
• Max. input voltage: 600 V.
• Max. nominal input voltage: 350 V.
• Maximum efficiency: 98 %.
• Protection: IP66, dust- and water-resistant.

• 1% high-accuracy power detection for precise control
• Seamless integration with Sigenergy devices, no setup required
• Top-class 100A direct connection power sensor with built-in CT
• 100ms data refresh rate, instantaneous data feed

• Single-phase hybrid inverter 12 kW: 2 MPPT.
• Max. input voltage: 600 V.
• Max. nominal input voltage: 350 V.
• Maximum efficiency: 98 %.
• Protection: IP66, dust- and water-resistant.
