Tu tienda de energía solar

• Dynamic charging 22 kW with integrated RCD.
• Automatic power adjustment to prevent overloads.
• IP65 mounting on wall or pole, Type 2 AC connector.

• Sigen EV DC Charger 12.5 kW: Includes 5 m CCS2 cable for fast and safe
• Max. stable bidirectional charging of 12.5 kW.
• Ultra-wide range: Full compatibility with EVs (150-1000 V) and CCS2 connector.
• IP66 protection, maintenance-free.

• Sigen EV DC Charger 25 kW: 5 m CCS2 cable for fast and safe charging.
• Max. stable bidirectional charging of 25 kW.
• Ultra-wide range: Full compatibility with EVs (150-1000 V) and CCS2 connector.
• IP66 protection, maintenance-free.

• Dynamic charging 7 kW with integrated RCD.
• Automatic power adjustment to prevent overloads.
• IP65 mounting on wall or pole, Type 2 AC connector.

HUAWEI Power meter DTSU666-FE smart meter. Only required in combination with the Huawei EV charging point SCharger in installations without PV inverters. Valid for three-phase and single-phase installations up to 100A - 3x CT 100A included.

Including cable (approx. 140 cm) and TS4 connector system
Robust anodized aluminum frame
High quality solar cells
Version with 10 busbars
rated power 510
rated voltage 43.00
current ratet 11.75
power tolerance +5 Wp
plug type MC4EVO2
L*W*H (mm) 2187 * 1102 * 35
short circuit current 12.35
open circuit current 51.90
Maximum system voltage 1500
cell type monocrystalline
Number of cells 150
Weight (kg): 26.50
31 unit per pallet

• 3 breaker positions reserved for SigenStor or other loads.
• Switch to backup mode in 0 ms, uninterrupted energy use.
• Reverse power flow protection of 350 ms from grid or generator.
• Uninterrupted power supply via PV+ESS/grid/generator.

Sigen Gateway HomeMax TP (Three-phase) for 12 inverters

3 breaker positions reserved for SigenStor or other loads
0 ms switchover to backup mode, worry-free energy use
Ready for generator, heat pump, or other controllable loads
Supports whole-home and partial-home backup
350 ms reverse power flow protection from grid and generator
Uninterrupted power supply via PV+ESS/grid/generator

Huawei SUN2000-25K-MB0 hybrid inverter, Pac rated 25000 W, compatible with Huawei LUNA batteries, 2 MPPT, compatible with Huawei single and dual power optimizers.

Potencia nominal: 110000W
12 seguidores MPP independientes.
Sin display.
IP 65.
Potencia máx. del generador fotovoltaico:165000 Wp STC
Tensión de entrada máx.1100 V
Rango de tensión del seguidor del MPP/tensión asignada de entrada: De 500 V a 800 V/ 585 V
Tensión de entrada mín./de inicio200 V/250 V
Corriente máx. de entrada/por seguidor del MPP: 26 A/40 A
Número de entradas de seguidores del MPP independientes/Strings por entrada de seguidores del MPP: 12/2

The Cerbo GX is a flexible communication centre that will take remote monitoring to the next level. With all the hardware connection possibilities to fit your every need.

25kw three-phase inverter hybrid- 4MPPT

Max. input voltage: 1100V
Max. Rated input voltage: 600V
Max. intensity per MPPT: 16A
Maximum efficiency:98.4%
Protection: IP66
10 year warranty

• IP66 protection rating, more reliable
• Plug & play, easy to use
• Support 2G / 3G / 4G communication

• Dynamic charging 11 kW with integrated RCD.
• Automatic power adjustment to prevent overloads.
• IP65 mounting on wall or pole, Type 2 AC connector.
