Solis 3P20kW 4G Three Phase Dual MPPT DC

1100V Three Phase Inverter
Features a maximum input current of 32A
Certified 0 injection
Protection against overvoltage, short circuit, output overcurrent and against DC reverse polarity
Standard 5-year warranty extendable up to 20 years

Solis-S5-3P12K-DC (12 kW - 2 MPPT)

1000V three-phase inverter
It has a maximum input current of 22A
Protection against overvoltage, short circuit, output overcurrent and against DC reverse polarity
Standard 5-year warranty extendable up to 20 years

Solis-S5-GR3P10K (10 kW - 2 MPPT)

1100V Three Phase Inverter
Features a maximum input current of 32A
Certified 0 injection
Protection against overvoltage, short circuit, output overcurrent and against DC reverse polarity
Standard 5-year warranty extendable up to 20 years

Solis S5-GR3P5K

Non-hybrid three-phase inverter
MPPT voltage range: 160-1000V
Maximum input voltage: 1100 V
Maximum input current: 16 A / 16 A
Number of MPPTs/Number of entries: 2/2
Protection against DC reverse polarity / output overcurrent and temperature
5 year warranty extendable up to 20 years

Solis S6 GR1P3K (3 kW - 2 MPPT)

2 MPPT non-hybrid single-phase inverter
Max input current: 14A
Max input voltage: 600V
DC reverse polarity / short circuit / overvoltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Solis S5-GR1P1.5K-M (1,5 kW)

Maximum input voltage: 600 V
Maximum input current: 12.5 A
Number of MPPTs/Number of entries: 1/1
97.3% maximum efficiency
Integrated AFCI (DC Arc Fault Circuit Protection)
5 year warranty extendable to 20 years

Solis S6-GR1P5K-DC (5kW - 2 MPPT)

2 MPPT non-hybrid single-phase inverter
Parallelizable up to 10 units
Max input current: 14A
Max input voltage: 600V
DC reverse polarity / short circuit / over voltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Solis S6-GR1P3K-M-DC-Meter (3 kW - 1 MPPT)

1 MPPT non-hybrid single-phase inverter
Parallelizable up to 10 units
Max input current: 14A
Max input voltage: 600V
DC reverse polarity / short circuit / over voltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Solis S6-GR1P6K-DC-Meter (6 kW - 2 MPPT)

2 MPPT non-hybrid single-phase inverter
Parallelizable up to 10 units
Max input current: 14A
Max input voltage: 600V
DC reverse polarity / short circuit / over voltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Solis-RAI-3K-48ES-5G-DC

Inverter - bidirectional charger
Rated output power: 3kw
Mains rated voltage: 220V/230V
Maximum output current: 20A
Anti-return protection of the battery / short circuit / temperature and output overcurrent

Solis S6-GR1P4K-DC (4kW - 2MPPT)

2 MPPT non-hybrid single-phase inverter
Parallelizable up to 10 units
Max input current: 14A
Max input voltage: 600V
DC reverse polarity / short circuit / over voltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Export Manager 5G (Para sistemas trifásicos)

Energy export manager for three-phase systems.
Monitor power generation and load consumption at all times.
Input voltage: 175~519V (L-L)
Rated voltage: 3/N/PE, 230V / 400V
Monitoring via WiFi/4G/LAN Stick (Optional)
Communication via Modbus (RS485)

Solis S5-GR3P15K 15KW (2 MPPT)

1100V Three Phase Inverter
Features a maximum input current of 32A
Certified 0 injection
Protection against overvoltage, short circuit, output overcurrent and against DC reverse polarity
Standard 5-year warranty extendable up to 20 years

Solis S5-GR3P6K

2 MPPT non-hybrid three-phase inverter
Parallelizable up to 10 units and discharge 0 jointly
Max input current: 16A
Max input voltage: 1100V
DC reverse polarity / short circuit / over voltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Solis-EPM1-5G

Energy export manager for single-phase systems
Input voltage: 100~300V (L-N)
Rated voltage: 1/N/PE, 230V
Monitoring via WiFi/4G/LAN Stick (Optional)
Communication via Modbus (RS485)

Solis S6-GR1P0.7K-M (700 W)

1 MPPT non-hybrid single-phase inverter
Max input current: 14A
Max input voltage: 600V
DC reverse polarity / short circuit / overvoltage / anti-islanding and temperature protection
It has an LCD screen for configuration and display of data in real time
5-year warranty (extendable up to 20 years)

Features:

Indirect measurement wattmeter, installation without the need to modify the customer's installation.
DIN35 rail mounting
LCD display for real time display of measurements
10m RS485 cable with Solis inverter connector included as standard.
Ability to use other toroidals with secondary at 5 amps simply by setting the transformation ratio

Solis 5G 110kW 3Ph Inverter, 10 MPPT

10 MPPT, 98.7% maximum efficiency
> 150% DC/AC ratio
High power tracking density 90 MPPT/MW
Compatible with bifacial modules
Maximum input voltage 1100 V
Communication:RS485, Optional: Wi-Fi, GPRS, PLC

Solis-255K-EHV-5G

14 MPPT
Nº strings máx. 28
Max imput voltgje 1500V
Voltaje de arranque 500V
98% Eficiencia máxima
Pantalla LCD
Comunicación RS485

Solis 110kW 5G Three Phase 8 MPPT DC

8 MPPT three-phase inverter (up to 16 input strings)
Maximum input voltage: 1100V
Maximum input current: 36 A / 32 A
Maximum efficiency: 98.5%
DC reverse polarity/temperature/short circuit and surge protection
5-year warranty (extendable up to 20 years)
